12F+12R independent shuttle shift

3600kg extremely light weight

500mm high ground clearance

55° super steering Angle

Minimum steering radius only 3.7m

Full hydraulic power steering system


Model Unit RV904/954/1104
Overall dimension (L×W × H) mm 4647×2031×2800
Wheelbase mm 2350
Minimum mass during operation kg 3600
Minimum ground clearance mm 500
Engine emission / National III
Rated power kw 66/70/81
Fuel consumption rate g/kW•h ≤235
Cluth type / Dry type, single action
Number of gears of the gearbox / 12F+12R independent shuttle shift
Tyre size (front wheel / rear wheel) / 9.5-24/16.9-30
Type of hydraulic lifting system / Split type
Maximum lifting capacity KN 23
Tillage control method / Position adjustment and floating control
Hydraulic output multiway valve / 2 groups
Hydraulic hitch / Three-point rear suspension, Category II
Traction force KN 28
PTO output power kW 65.4-81
