Choose options
25HP Euro 5 engine
8F+8R Meshing sleeve gearshift
Reinforced front axle
300mm ground clearance
Steering radius only 3m
Hydraulic-driven steering system
The rear track adjustable
Model | Unit | RD254/254-A |
Overall dimension (L×W × H) | mm | 3300×1425×1860 |
Wheelbase | mm | 1639 |
Minimum Mass during operation | kg | 1530 |
Minimum ground clearance | mm | 300 |
Engine emission | / | Euro 5 |
Rated power | kw | 18.4 |
Fuel consumption rate | g/kW•h | ≤245 |
Cluth type | / | Dry type, double action |
Number of gears of the gearbox | / | 8F+8R Meshing sleeve gearshift |
Tyre size (front wheel / rear wheel) | / | 6.0-16/11.2-24 |
Type of hydraulic lifting system | / | Semi-split type |
Maximum lifting capacity | KN | ≥4.2 |
Tillage control method | / | Position adjustment and floating control |
Hydraulic output multiway valve | / | 2 groups |
Hydraulic hitch | / | Three-point rear suspension, Category I |
Traction force | KN | 6.3 |
PTO output power | kW | 16.9 |
Power output speed | r/min | 540/1000 |
Safety shelf or cab | / | Safety shelf or Heater cab |
